Cold and hot laminating on large format materials, such as outdoor & indoor pictorial advertisement, photo advertisement, studio image, silk-screen printing, X-banner, PVC plate, KT plate etc and laminating on surface protection such as panel, glass, sections,acrylic, wooden door etc.
• Infrared ray control temperature accurately without harming on silicone roller.
• Unilateral linkage, easily up and down.
• Two Methods of laminating: Automatic/ Foot control.
• Variable speed regulation.
• With reversing function.
• Uncovering back paper and picking up finished product automatically.
• Only need one person to operate to save cost.
• Heating to 60 degree, avoiding bubble and snowflake thoroughly.
• High rate of lamianting and finished products, whole film of 50m don't bevel.
• Film and paper tightness-degree system makes the cold lamination have good tension, reduce the risk of laminating fold.
Laminating width: ≦ 1580 mm
Laminating thickness: 50 mm
Laminating speed: 1-10 m/min
Laminating temperature: 60 ℃
Power: 90 W
Voltage: 110V / 220V
Frequency: 50Hz-60 Hz
Max roll film OD: 200 mm
The diameter specification of Roll Film: 2.25 inches, 3 inches
Method of pressure adjustment: Pneumatic
Work type: Pedal or Automatic
Warm-up time: 10 min
Product size: 198*57*124 mm
Pack size: 209*69*685 mm
Packing: Wooden case
